Quanta Systems Chrome

The Quanta System Chrome is an advanced, multi-application laser platform designed to address a wide spectrum of dermatological and aesthetic concerns. Combining cutting-edge Q-Switched Nd:YAG technology with modular expandability, Chrome offers over 50 treatment indications, making it a versatile solution for modern aesthetic practices.

Technology & Wavelengths

• Q-Switched Nd:YAG Laser:

  • Wavelengths: 1064 nm and 532 nm

  • Pulse Duration: Nanoseconds (6 ns)

  • Repetition Rate: Up to 20 Hz

  • Emission Modes: Q-Switched and Opti-Pulse

• Optional Modules:

  • Er:YAG 2940 nm: For ablative and fractional skin resurfacing

  • Twain IPL: Broad-spectrum treatments including hair removal and acne

  • Pulsed 1064 nm: For vascular lesions and nail fungus

Handpieces & Accessories

• OptiZoom: Adjustable spot sizes from 2 mm to 8 mm in 0.25 mm increments, featuring automatic spot size detection for precision treatments.

• NaturaPeel: Designed for carbon-assisted laser peels, enhancing skin brightness and texture.

• Rosso: 694 nm Q-Switched laser handpiece targeting pigmented lesions and tattoos without purpura.

• Fractional Handpieces:

  • Deep Fractional (DF): For scars, wrinkles, and skin tightening.

  • High Coverage (HC): Targets pigmented lesions on sensitive skin.

• Twain IPL & Twain 2940: Expand treatment capabilities to include photo-epilation, acne treatment, and ablative procedures.

Skin Apps: Tailored Treatment Protocols

Chrome's proprietary Skin Apps are pre-set treatment protocols combining specific wavelengths and handpieces to address various skin concerns effectively. These applications simplify the treatment process, ensuring consistent and optimized results.

Clinical Applications

• Pigmented Lesions: Treatment of age spots, freckles, melasma, and café-au-lait macules.

• Vascular Lesions: Effective on conditions like port wine stains, telangiectasias, and spider angiomas.

• Tattoo Removal: Targets multicolored tattoos, including challenging hues like red, green, and blue.

• Skin Rejuvenation: Improves skin tone, texture, and reduces fine lines.

• Hair Removal: Permanent reduction across various skin types.

• Acne and Acne Scars: Reduces active acne and minimizes scarring.

• Nail Fungus (Onychomycosis): Non-invasive treatment option.

Technical Specifications

• Laser Class: Class 4

• Pulse Durations: Nanosecond, microsecond, and millisecond ranges

• Ergonomics: Trolley-mounted design for mobility and space efficiency

• User Interface: Touchscreen display with intuitive controls

• Cooling Systems: Compatible with contact or air cooling systems for enhanced patient comfort
