Quanta Light 4V Evo Series-2020

The Quanta Light 4V EVO Series is a cutting-edge, multi-wavelength laser platform engineered for comprehensive aesthetic and dermatological treatments. Manufactured by Quanta System in Italy, this device integrates up to four laser wavelengths—755 nm (Alexandrite), 1064 nm and 532 nm (Nd:YAG), and optionally 1320 nm (Nd:YAG)—to address a wide array of skin concerns with precision and efficacy.

Key Features

• Multi-Wavelength Capability: Combines Alexandrite 755 nm, Nd:YAG 1064 nm, Nd:YAG 532 nm, and optional Nd:YAG 1320 nm wavelengths, enabling versatile treatment options.

• Advanced Pulse Control: Offers adjustable pulse durations ranging from 0.3 to 300 ms and burst modes with up to three pulses, allowing customization for various skin types and conditions.

• High Fluence and Repetition Rates: Delivers maximum fluence up to 500 J/cm² and repetition rates up to 10 Hz, ensuring efficient and effective treatments.

• Versatile Handpieces: Equipped with multiple detachable handpieces featuring variable and fixed spot sizes (2–18 mm), including options for Q-Switched and long-pulsed modes.

• Integrated Cooling Systems: Features an optional contact skin cooler and compatibility with external air cooling units to enhance patient comfort during procedures.

• Upgradeable with TWAIN Accessories: Supports additional handpieces like the TWAIN 2940 nm Er:YAG laser for ablative treatments and TWAIN IPL for a range of dermatological applications.

Clinical Applications

• Hair Removal: Effective on all skin types, including tanned and darker skin tones, utilizing the 755 nm and 1064 nm wavelengths.

• Vascular Lesions: Treats facial and leg telangiectasia, hemangiomas, and other vascular conditions using the 532 nm and 1064 nm wavelengths.

• Pigmented Lesions: Addresses benign pigmented lesions such as lentigines and nevi with the 755 nm and 532 nm wavelengths.

• Skin Rejuvenation: Combines multiple wavelengths to improve skin texture, tone, and overall appearance.

• Acne and Scarring: Utilizes the optional 1320 nm wavelength and TWAIN 2940 nm handpiece for treating inflammatory acne and acne scars.

Technical Specifications

• Pulse Duration: Adjustable from 0.3 ms to 300 ms.

• Repetition Rate: Up to 10 Hz in single-wavelength mode; up to 5 Hz in mixed-wavelength mode.

• Fluence: Maximum fluence of 500 J/cm² for each wavelength, software-limited.

• Beam Delivery: Via optical fiber with detachable handpieces.

• Cooling Systems: Closed water circuit with water-air exchanger; optional contact skin cooling and air cooling systems.

• Electrical Requirements: Operates on 200–240 Vac, 50/60 Hz, with a power consumption of 3.7 kVA.

• Dimensions & Weight: Measures 530 mm (W) x 1043 mm (D) x 1060 mm (H) and weighs 150 kg.

The Quanta Light 4V EVO Series stands out as a versatile and advanced laser system, offering customizable treatments across a range of dermatological and aesthetic applications. Its integration of multiple wavelengths and proprietary technology ensures effective results with enhanced patient safety and comfort.
